Additional information
| Brand | SKF |
|---|---|
| MPN | 18817 |
| Model | Rotary Shaft Seal: |
| Number of Lips | 1 |
| Lip Material | Nitrile Rubber |
| Inside Diameter | 1.875 in |
| Outside Diameter | 3 in |
| Overall Width | 0.313 in |
| Maximum Pressure | 10 psi |
| Seal Design | CRW1 |
| Seal Type | Wave Lip Seal |
| Contact Type | Contact Seal |
| Spring Type | Garter |
| Spring Reinforcement | Yes |
| Spring Material | Carbon Steel |
| For Fluid Type | For Fluid TypeAnimal and Vegetable Oils; Diesel; Gasoline; Greases; Hot Water; Light Heating Oil; Mineral Oils |
| Case Coating | Acrylic |
| Temperature | -40 °C to 100 °C |
| Maximum Surface Speed | 7.64 mps |
| Maximum Rotational Speed | 3,060 RPM |
| Resistance Properties | Chemical Resistant |
| Standards | ASTM D1418; ASTM D1600; DIN 7728 Part 1; ISO Certified 1043-1; ISO Certified 1629 |
| UPC | 0085311020589 |
