Additional information
| Brand | Mid-West Instrument |
|---|---|
| MPN | 240-SC-02-O(AAA)-50H |
| Model | Differential Pressure Gauge with Switch |
| Series | 240 |
| Pressure Range | 0 to 50 in wc |
| Accuracy | ±3-2-3% |
| Nominal Dial Size | 4-1/2 in |
| Hazardous Location Rating | Class 1, Division 2, Groups A, B, C, D; Class 2, Division 2, Groups F, G |
| IP/NEMA Rating | NEMA 4X |
| Maximum Working Static Pressure | 1,500 psig |
| Switch Contact Type | SPDT |
| Housing Material | 316 Stainless Steel |
| Application | Filtration Monitoring; Pumps; Separators; Strainers; Valves |
| Sensor Type | Diaphragm |
| Process Connection Size | 1/4 in NPT |
| Case Material | Plastic |
| Case Diameter | 6-3/16 in |
| Standards | ATEX; CE; CSA; EU RoHS2 Compliant; IEC Ex; KOSHA Ex IIB + H2; NEMA 4X; UL |
| Ambient Operating Temperature Range | -40° to 185°F (-40° to 85°C) |
| Lens Material | Acrylic |
| Movement Material | Ceramic |
| O-Ring Material | Buna-N |
| Switch Electrical Requirements | 0.25A @ 125V AC/DC; 3W |
