Autonics MD2U-MD20 Stepping Motor Driver 2 Phase 2.0A/Phase 24-35 VDC

Autonics MD2U-MD20 Stepping Motor DriverFree Shipping in the USA from St. Louis, MO. Features adjustable run/stop current and self-diagnosis test function, this stepping motor driver performs very slow rotations and high-precision positioning.Offers full, half, and microstep in one driver, and is compatible with Programmable Motion Controller (PMC) or Programmable Logic Controller (PLC) with a pulse generation option.Match phase and amps per phase to the stepper motor rating.Product NumberMD2U-MD20TypeStepping Motor DriverPhase2Voltage24-35 VDCAmps Per Phase2.0Run MethodUnipolarResolution / Microstep Divisions1, 2, 4, 5, 8, 10, 16, 20Max. Input Pulse Frequency50 kppsMin. Input Pulse Width10 microsecHeight4-1/8"Width1-9/16"Depth3-1/16"Mounting2-HoleMounting Pattern3.799 In on CenterStandardsCE, RoHSFor Use WithAutonics Stepping Motor A2K-M243; A4K-M245, A16K-G268Thank you for your interest in this item. We do our best to accurately describe each item as best as possible. We ask you to please review all photos and the description of the item’s condition prior to purchase. If you have any questions or require any additional information send us a message and we will happily assist you in a timely manner. Thank

Autonics MD2U-MD20 Stepping Motor Driver

Free Shipping in the USA from St. Louis, MO.

  • Features adjustable run/stop current and self-diagnosis test function, this stepping motor driver performs very slow rotations and high-precision positioning.
  • Offers full, half, and microstep in one driver, and is compatible with Programmable Motion Controller (PMC) or Programmable Logic Controller (PLC) with a pulse generation option.
  • Match phase and amps per phase to the stepper motor rating.
Product Number

MD2U-MD20
Type

Stepping Motor Driver
Phase

2
Voltage

24-35 VDC
Amps Per Phase

2.0
Run Method

Unipolar
Resolution / Microstep Divisions

1, 2, 4, 5, 8, 10, 16, 20
Max. Input Pulse Frequency

50 kpps
Min. Input Pulse Width

10 microsec
Height

4-1/8"
Width

1-9/16"
Depth

3-1/16"
Mounting

2-Hole
Mounting Pattern

3.799 In on Center
Standards

CE, RoHS
For Use With

Autonics Stepping Motor A2K-M243; A4K-M245, A16K-G268

Thank you for your interest in this item. We do our best to accurately describe each item as best as possible. We ask you to please review all photos and the description of the item’s condition prior to purchase. If you have any questions or require any additional information send us a message and we will happily assist you in a timely manner. Thank
