Dayton 12T648 5HP 240V 60 Hz 1PH 35.2A 3450 RPM PSC Cast Iron Grinder Pump -
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Brand | Dayton |
| MPN | 12T648 |
| Supply Voltage | 240V |
| Rated Power | 1.5 hp (1.1 kW) |
| Discharge Port Diameter | 11" |
| Unit Quantity | 1 |
| Unit Type | Unit |
| Model | Grinder Pump |
| HP | 5 hp |
| Rated Voltage | 240V AC |
| Hz | 60 |
| Phase - Pumps | 1 |
| Amps | 35.2 A |
| Motor Type | PSC |
| Body Material | Cast Iron |
| Impeller Material | Brass |
| Shaft Seal Material - Pumps | Silicon Carbide; Ceramic; Stainless Steel |
| Flow Rate @ 10 Ft. of Head | 99 gpm |
| Flow Rate @ 15 Ft. of Head | 99 gpm |
| Flow Rate @ 20 Ft. of Head | 99 gpm |
| Flow Rate @ 40 Ft. of Head | 99 gpm |
| Max. Head | 130 ft |
| Min. Sump Pit Dia. | 24" |
| Body Dia. | 11" |
| Overall Height | 30-1/4 in |
| Cord Length | 20 ft |
| Discharge | 2-1/2 in Flanged |
| Overall Length | 30-1/4 in |
| Max. Diameter Solids | 1/2 in |
| Max. Liquid Temp. | 140 °F |
| Duty Cycle | Continuous |
| RPM | 3450 RPM |
| Agency Compliance | CUS |
Dayton 12T648 5HP 240V 60 Hz 1PH 35.2A 3450 RPM PSC Cast Iron Grinder Pump
