Dayton 36VF43 10HP 3PH 1770 RPM 230/460V 24.8/12.4A General Purpose Motor -
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Brand | Dayton |
| MPN | 36VF43 |
| Rated Load (HP) | 10 |
| Current Type | AC |
| Nominal Rated Input Voltage | 230/460V AC |
| AC Phase | 3 |
| Service Factor | 1.15 |
| NEMA Frame Suffix | 213/5T |
| Shaft Diameter | 1 3/8 in |
| Special Motor Construction | N/A |
| IEC Frame Size | 213/5T |
| AC Frequency Rating | N/A |
| AC Motor Type | General Purpose Motor |
| Enclosure Type | Open Dripproof |
| Unit Quantity | 1 |
| Unit Type | Unit |
| Model | General Purpose Motor |
| Phase | Three |
| HP | 10 |
| Nameplate RPM | 1,770 |
| No. of Speeds | 1 |
| Voltage | 230/460V AC |
| Full Load Amps | 24.8/12.4 A |
| Hz | 60 Hz |
| Motor Service Factor | 1.15 |
| Max. Ambient Temp. | 104 °F |
| Motor Enclosure Design | Open Dripproof |
| Motor Shaft Rotation | CW/CCW |
| Motor Mounting Type | Rigid Base |
| Motor Mounting Position | Horizontal |
| Motor Shaft Design | Keyed |
| Motor Frame Material | Rolled Steel |
| Shaft Dia. | 1-3/8" |
| Shaft Length | 3-3/8" |
| Length Less Shaft | 14-3/8 in |
| Motor Bearings | Ball |
| Overall Length | 17-3/4 in |
| Standards | CE; CSA; UL |
| RPM Range | 1,701-1,800 |
Dayton 36VF43 10HP 3PH 1770 RPM 230/460V 24.8/12.4A General Purpose Motor
