Interstate 428-72811 8in Jaw 8-1/4in Opening Swivel Base Machine Vise
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
This is a new Interstate 428-72811 single-station precision milling machine vise featuring an 8.000 in jaw width and 8-1/4 in maximum jaw opening, mounted on a full 360° swivel base with a graduated degree scale reading in 10° increments — clearly visible in the photos — allowing repeatable angular workholding setups without removing the vise from the table. The cast iron body is fitted with a ground steel fixed jaw and a sliding movable jaw driven by an ACME-thread leadscrew with a socket-drive spindle (socket handle included, as seen in photos), and the base incorporates T-slot mounting slots for standard milling machine tables. The precision-ground jaw faces and hardened steel jaws provide consistent clamping force and jaw parallelism suitable for milling, drilling, and boring operations on knee mills and bed mills. Condition is new; surface oxidation visible in photos is cosmetic and consistent with storage of an uncoated cast iron/steel workholding tool.
Product Specifications
| Brand | Interstate |
| MPN | 428-72811 |
| Jaw Width | 8.000 in |
| Max Jaw Opening | 8-1/4 in (8.25 in) |
| Number of Stations | 1 (Single-Station) |
| Swivel Base | Yes, 360° graduated swivel base |
| Degree Scale | Graduated scale, 10° increments |
| Body Material | Cast iron |
| Jaw Material | Hardened steel |
| Jaw Face | Precision ground |
| Drive Type | ACME leadscrew, socket drive |
| Mounting | T-slot, milling machine table |
| Condition | New |
