The Kennametal RNGN120700T01020 (ANSI: RNG45T0420) is a round (R), 0° clearance (N), ground (G), no chipbreaker (N) PCBN/CBN turning insert in grade KY830, supplied as a new factory pack of 5, made in the USA. Decoded per ISO 1832: inscribed circle (IC) = 12.7 mm (1/2 in), thickness = 7.00 mm, cutting edge length = T01020 tip geometry with a 2.0 mm nose radius and full-face CBN construction. KY830 is Kennametal's solid polycrystalline cubic boron nitride (PCBN) grade engineered for hard turning of hardened steels (45–65 HRC), gray and ductile cast irons, and powder-metal components at high surface speeds without coolant. The round insert geometry (RNGN) maximizes edge strength and is suited for finish and semi-finish turning passes where edge security and surface finish are critical; compatible Kennametal toolholders use the RNG insert pocket (e.g., CRSNR/L series). The first image shows a single insert resting on a gray surface with a visible oblong chip-lock slot on the face, confirming the full solid CBN construction and 0° relief geometry consistent with the RNGN designation.
Product Specifications
| Brand | Kennametal |
| MPN (ISO) | RNGN120700T01020 |
| MPN (ANSI) | RNG45T0420 |
| Grade | KY830 |
| Grade Material | Solid PCBN (Cubic Boron Nitride) |
| Insert Shape | Round (R) |
| Clearance Angle | 0° (N) |
| Tolerance Class | Ground (G) |
| Chipbreaker | None (N) — flat top |
| Inscribed Circle (IC) | 12.7 mm (1/2 in) |
| Insert Thickness | 7.00 mm |
| Nose Radius | 2.0 mm (T01020 designation) |
| Cutting Edge | Full-face solid CBN |
| Quantity per Pack | 5 |
| Country of Origin | USA |
| Application | Hard turning, cast iron, powder metal |
| Workpiece Hardness Range | 45–65 HRC |
| Condition | New |
