The Kennametal RPPT1204M0SGP is a 12 mm round (circular) positive-rake carbide milling insert in the KCPM40 grade, manufactured in the USA and sold here new in the original factory 5-piece package. Decoding the ISO-style designation: R = round shape, PP = double-positive geometry (11° clearance both sides), T = close tolerance, 1204 = 12 mm IC / 04 mm thickness, M0 = no hole chamfer / torx-style clamping, SGP = Kennametal's "DAISY" medium chipbreaker geometry optimized for general-purpose milling. KCPM40 is a PVD-coated (AlTiN/TiAlN-family) uncoated-substrate cermet/carbide grade engineered for medium-duty milling of steels, stainless steels, and cast irons at moderate to high cutting speeds with excellent edge toughness. The SGP (Secure Grip Positive) Daisy chipbreaker features a multi-lobed seating surface that locks the insert against the pocket under cutting loads, reducing micro-movement and extending tool life in face milling, copy milling, and ramping operations on compatible Kennametal round-insert milling bodies such as the RPHH and similar cartridge-style cutters.
Product Specifications
| Brand | Kennametal |
| MPN | RPPT1204M0SGP |
| Grade | KCPM40 |
| Insert Shape | Round (R) |
| Inscribed Circle (IC) | 12 mm |
| Insert Thickness | 4 mm |
| Clearance Angle | 11° (positive, code PP) |
| Tolerance Class | T (close tolerance) |
| Chipbreaker | SGP – DAISY Medium Geometry |
| Coating | PVD (KCPM40 grade) |
| Application | General-purpose milling – steels, stainless, cast iron |
| Country of Origin | USA |
| Quantity per Package | 5 inserts |
| Kennametal Item No. | 5542246 |
| Condition | New |
