WEG 06012ES3EOW405T-W22 60HP 6P 3PH 208-230/460V Oil Well Pump Electric Motor -
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
| Brand | WEG |
| MPN | 06012ES3EOW405T-W22 |
| Rated Load | 60 HP |
| Current Type | 175-159/79.3 A |
| AC Frequency Rating | 60 Hz |
| Unit Quantity | 1 |
| Unit Type | Unit |
| Model | Oil Well Pump Electric Motor |
| Frame | 404/5T |
| Output | 60 HP (45 kW) |
| Number of Poles | 6 |
| Frequency | 60 Hz |
| Rated speed | 1145 RPM |
| Slip | 4.58 % |
| Rated voltage | 208-230/460 V |
| Rated current | 175-159/79.3 A |
| L. R. Amperes | 1070-967/484 A |
| LRC | 6.1x(Code H) |
| No Load Current | 85.1-77.0/38.5 A |
| Rated Torque | 275 ft.lb |
| Locked Rotor Torque | 320% |
| Locked Rotor Time | 41s (cold) 23s (hot) |
| Moment of Inertia (J) | 38.1 sq.ft.lb |
| Design | D |
| Insulation Class | F |
| Service factor | 1.15 |
| Temperature Rise | 80K |
| Duty Cycle | Cont.(S1) |
| Starting Method | Direct On Line |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Degree of Protection | IP55 |
| Enclosure | IC411 - TEFC |
| Mounting | F-2 |
| Rotation¹ | Both (CW and CCW) |
| Noise level² | 68.0 dB(A) |
| Frame Material | Cast Iron |
| Impregnation Method | Constant Resin Flow |
| Regreasing System | At Drive end and Non-drive end |
| Flange | Without |
| Main terminal box hole | NPT 3" |
| Shaft Material | SAE 4140 Carbon Steel |
| Drain | Rubber, automatic |
| Grounding Lugs | Double |
WEG 06012ES3EOW405T-W22 60HP 6P 3PH 208-230/460V Oil Well Pump Electric Motor
